2E PowerLink S310 Network Adapter
SKU: 2E-S310
2E PowerLink S310 is a highly integrated and efficient Gigabit network adapter. The device provides data transfer speeds: 10/100 Mbit/s in half-duplex mode (Half-Duplex); 20/200/2000 Mbit/s in duplex mode (Full-Duplex).
- RTL8111 Chipset
- 32-bit PCI Express interface
- IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p, CSMA/CD, TCP/IP Network standards and protocols
- 10/100/1000 Mbit/s RJ45 Port
- LED indicator 1,000 M Link/Act, 100 M Link/Act, Duplex
Characteristics
Main:
| Type | network adapter |
| Appointment | internal |
| Support | Windows XP / Windows 7 / Mac OS / Windows 8 / Windows 10 / Windows 11 |
| Interface | PCI Express 32-bit |
| Сhipset | RTL8111H |
| Network Standards Support | IEEE 802.3 / IEEE 802.3u / IEEE 802.3ab / IEEE 802.3x Flow Control / 802.1q / 802.1p |
| Number of RJ-45 connectors | 1 10/100/1000 Mbps |
| Network Protocol Support | CSMA/CD / TCP/IP |
| Supported functions | Wake on LAN |
| Operating temperature | 0°C - 40°C |
| Storage temperature | -40 to 70 °C |
| Data transfer speed | 10/100 Mbps Half-Duplex / 20/200/2000 Mbps Full-Duplex |
| Indicators | LED indicator: 1000M Link/Act, 100M Link/Act, Duplex |
| Cable types | 10BASE-T: UTP cable categories 3, 4, 5 (max. length 100m) / EIA/TIA-568 100Ω STP (max. length 100m) / 100BASE-TX: UTP cable categories 5, 5e (max. length 100m) / 1000Base-T: UTP cable categories 5, 5e (max. length 100m) |
Physical:
| Humidity | 10% to 90% when used without condensation / 5% to 90% when stored without condensation |
Features
- RTL8111 Chipset
- 32-bit PCI Express interface
- IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p, CSMA/CD, TCP/IP Network standards and protocols
- 10/100/1000 Mbit/s RJ45 Port
- LED indicator 1,000 M Link/Act, 100 M Link/Act, Duplex
The adapter is fully compatible with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab standards, supports 802.3x Flow Control and Wake-on-LAN technologies, as well as 10/100/1000 Mbit/s network speed automatic negotiation technology. Compatible with Windows XP/7/8/10/11, Mac OS.
