2E HI2500 Home inverter, 2500W
The 2E HI2500 inverter with a capacity of 2,500 W is designed to convert 24 V direct current to 230 V alternating current. It can be used for any office or home loads, including resistive, inductive and electric motors and as a UPS for computer equipment and electronics in the event of a power outage. The model is compatible with generators, because it is possible to configure the interaction between the inverter and the generator.
- Pure sine wave
- External batteries are selected for the desired autonomy time
- Built-in protection functions
- Compatibility with generators
- ECO mode
- LCD screen
- Signal buzzer
- No socket, connection is via Terminal block
- The possibility to choose 220/230/240 V output voltage
- The possibility to choose the charging current
| Type | Inverter |
| Effective output power, W | 2500 |
| Input voltage range, V | 24 x DC, 156-294, (network mode), 0-264, (bypass mode) |
| Input frequency, Hz | 50-60 |
| Output voltage range, V | AC: 220/230/240 ± 5% |
| Output frequency, Hz | 50-60 |
| Inverter overload | 150% for 10 s (switch to bypass mode), 125% for 60 s (mains mode), 110% for 120 s (mains mode), 150% for 5 s (shutdown), 125% for 10 s (bypass mode), 110% for 60 s (bypass mode) |
| Sockets | Terminal block |
| Display | Yes |
| Operating temperature | 0-40 °C |
| Relative humidity | ≤ 93% |
| Colour | Black |
| Protection | Overload protection, short circuit protection, low voltage protection, over voltage protection, over temperature protection, over low battery protection |
| Dimensions (WxDxH), mm | 293x280x160 |
| Weight, kg | 32 |
| Manufactured | China |
| Warranty | 2 years |
The inverters are particularly in demand and popular now. Among the advantages, it is worth noting a wide range of input voltage, the ability to work in overload mode.
The 2E HI2500 inverter has built-in protection functions such as overvoltage, short circuit, undervoltage, overcharge, overheat and critical discharge.
2E HI2500 will be suitable for solving tasks in the event of an emergency shutdown of the power supply or the unavailability of the centralized power grid, in particular, it will allow to start a boiler or a refrigerator using a generator.
